Product range
Barcode scanning products
Thirteen models across three hardware lines plus a software decoding option, all running Dokivision decoding technology. Pick by form factor, then compare sensors, interfaces and size.
01OEM scan engines
Scan Engines
Miniature 2D imaging engines that give your device a complete barcode reader in a few cubic centimetres.
Scan Engines
SE10
Compact 2D scan engine for high-volume OEM integration
- Sensor640 × 480, global shutter
- Field of view40.8° × 32°
- InterfacesUART TTL · USB HID · USB VCOM
Scan Engines
EL13
Compact 2D scan engine with red laser aiming
- Sensor640 × 480, global shutter
- Frame rateUp to 100 fps
- Field of view36.0° × 28.0°
Scan Engines
SE20
Megapixel global-shutter 2D scan engine
- Sensor1280 × 800, global shutter
- Field of view39° × 26°
- Min. resolution3.3 mil
Scan Engines
SG20
Megapixel 2D scan engine with laser aiming
- Sensor1280 × 800, global shutter
- AimingLaser
- Field of view39° × 26°
Scan Engines
E20
Ultra-compact megapixel engine for software decoding
- Sensor1280 × 800, global shutter
- Frame rateUp to 60 fps
- Field of view39.5° × 26.1°
02Embedded & fixed-mount modules
Scan Module
Ready-to-mount readers for kiosks, turnstiles, counters and production lines.
Scan Module
EM20
Embedded 2D scan module for kiosks and turnstiles
- Sensor640 × 480 CMOS
- Field of view72° × 54°
- InterfacesUSB · TTL · RS485
Scan Module
EM48
Compact embedded 2D scan module for unattended terminals
- Sensor640 × 480, global shutter
- Field of view74° × 65°
- InterfacesUSB · RS232
Scan Module
EM95
Wide-angle embedded 2D scan module, industrial grade
- Sensor1280 × 800, global shutter
- Field of view60° × 40°
- InterfacesUSB · RS232
Scan Module
SC80
Counter-top fixed-mount scanner for checkout and automation
- Sensor1280 × 800, global shutter
- Motion tolerance3.5 m/s
- Field of view46° × 30°
03Handheld & desktop scanners
Barcode Scanner
Finished scanners powered by Dokivision engines for daily use in stores, warehouses and factories.
Barcode Scanner
DTS301
Desktop 2D barcode scanner for retail and mobile payment
- SensorGlobal-shutter CMOS
- Field of view40.8° × 32°
- InterfacesUART TTL · USB HID · USB VCOM
Barcode Scanner
HS21
Industrial handheld barcode scanner for logistics and manufacturing
- Sensor640 × 480, global shutter
- Field of view40.8° × 32°
- InterfacesUART TTL · USB HID · USB VCOM
Barcode Scanner
HS31
High-performance handheld 2D scanner
- Field of view40.8° × 32°
- InterfacesUSB · USB-COM
- ProtectionIP52
Barcode Scanner
HS230
Industrial handheld 2D scanner with IP52 protection
- Field of view51° × 43°
- InterfacesUSB · USB-COM · RS232
- ProtectionIP52
04Software decoding
Soft Decode
Dokivision decoding algorithms running on your own processor instead of on a decoder chip.
With soft decode, the scan engine captures the image and your device’s processor does the decoding, using the Dokivision decoding library. Removing the decoder from the engine makes the hardware smaller, lighter and lower in cost, while you keep full control over decoding settings, data handling and updates. It is the natural choice for Android and Linux devices that already have processing power to spare.
How soft decode works- Decoding library for Android and Linux
- Runs on the host CPU, with NPU acceleration where available
- Same 1D / 2D symbologies as our hardware decoders
- Damaged and low-contrast code recovery built in
At a glance
Compare all models
Key figures from each datasheet. Open a product page for full specifications and drawings.
| Model | Type | Highlights | |
|---|---|---|---|
| DTS301 | Barcode Scanner | SensorGlobal-shutter CMOSField of view40.8° × 32°InterfacesUART TTL · USB HID · USB VCOM | Details |
| E20 | Scan Engines | Sensor1280 × 800, global shutterFrame rateUp to 60 fpsField of view39.5° × 26.1° | Details |
| EL13 | Scan Engines | Sensor640 × 480, global shutterFrame rateUp to 100 fpsField of view36.0° × 28.0° | Details |
| EM20 | Scan Module | Sensor640 × 480 CMOSField of view72° × 54°InterfacesUSB · TTL · RS485 | Details |
| EM48 | Scan Module | Sensor640 × 480, global shutterField of view74° × 65°InterfacesUSB · RS232 | Details |
| EM95 | Scan Module | Sensor1280 × 800, global shutterField of view60° × 40°InterfacesUSB · RS232 | Details |
| HS21 | Barcode Scanner | Sensor640 × 480, global shutterField of view40.8° × 32°InterfacesUART TTL · USB HID · USB VCOM | Details |
| HS230 | Barcode Scanner | Field of view51° × 43°InterfacesUSB · USB-COM · RS232ProtectionIP52 | Details |
| HS31 | Barcode Scanner | Field of view40.8° × 32°InterfacesUSB · USB-COMProtectionIP52 | Details |
| SC80 | Scan Module | Sensor1280 × 800, global shutterMotion tolerance3.5 m/sField of view46° × 30° | Details |
| SE10 | Scan Engines | Sensor640 × 480, global shutterField of view40.8° × 32°InterfacesUART TTL · USB HID · USB VCOM | Details |
| SE20 | Scan Engines | Sensor1280 × 800, global shutterField of view39° × 26°Min. resolution3.3 mil | Details |
| SG20 | Scan Engines | Sensor1280 × 800, global shutterAimingLaserField of view39° × 26° | Details |
Start a project
Not sure which model fits?
Send us your application details and we will recommend the right engine, module or scanner.
